| Perm ID | Sage ID | JSS ID | Unit | Location | Early Equip. |
Final Equip. |
Oper. Date |
Inact. Date |
Notes |
|---|---|---|---|---|---|---|---|---|---|
| P-69 | Z-69 | 756 | Finland AFS, MN | FPS-3/-20/-64; FPS-5; FPS-6; FPS-6A/-90; FPS-26A | FPS-27; FPS-26A | Jul-52 | 15-Aug-80 | BUIC-II. GATR retained until JSS switchover. Radar site replaced by Nashwauk, MN, JSS radar site. | |
| CG16 / P-69E | C-15A / Z-69E | Nipigon, ON, CN | Planned Gap-Filler Annex. Partially built. Never operational. | ||||||
| CG35 / P-69F | Z-69F | Whitefish Lake, ON, CN | Planned Gap-Filler Annex. Not built. Never operational. | ||||||
| P-69A | Franklin, MN ** | (FPS-18 planned) | Gap-Filler Annex. ** In early ADC plans, but never was built. Apparently the nearby gap-filler radar site at Aurora, MN was built instead. | ||||||
| P-69B | Z-69B / Z-16B | Upson, WI | FPS-18 | Nov-59 | Jun-64; Dec-67 | Gap-Filler Annex. Building is still extant. Site designation changed from Z-69B to Z-16B in 1964. | |||
| P-69C | Z-69C / Z-35H | Askov, MN | FPS-14 | Oct-57 | Jun-64; Dec-67 | Gap-Filler Annex. Site designation changed from Z-69C to Z-35H in 1964. | |||
| P-69D | Z-69D | Aurora, MN | FPS-18 | Dec-60 | Jun-68 | Gap-Filler Annex. Building is still extant. |
Current Use: Deactivated.
NOTICE:Some photos and documents may be marked with varying degrees of classification, up to SECRET. Data so marked is the way it was delivered from official USAF sources, and have been completely declassified. To the best of our knowledge, no currently classified data is stored on this site.The following site information is available: |
   |
