Information for Keno AFS, OR

Latitude: 42-04-08 N, Longitude: 121-58-20 W

Call Sign(s): Paralize

Perm ID	Sage ID	JSS ID	Unit	Location	Early Equip.	Final Equip.	Oper. Date	Inact. Date	Notes
TM-180	Z-180	J-82	827	Keno AFS, OR	FPS-20A; FPS-67; FPS-6A; FPS-6A/-90	FPS-67B; FPS-6A; FPS-90. (FPS-67B only for JSS)	1959		BUIC-III. 827th Air Defense Group inactivated 30 Sept 1979. FAA joint-use site now, called ''Klamath Falls'' (data-tie only); FPS-90 sent to Salem, OR, JSS site (Z-345).
TM-180A	Z-180A			Yreka, CA	FPS-18		Sep-59	Dec-60	Gap-Filler Annex. Building is still extant. Located atop Gunsight Peak.
TM-180B				La Pine, OR					Gap-Filler Annex. Located atop Paulina Peak. Reportedly, the radar tower blew down during winter of 1958 - 1959, and was never rebuilt. The building was reportedly removed in 1987.

Perm ID

Sage ID

JSS ID

Unit

Location

Early
Equip.

Final
Equip.

Oper.
Date

Inact.
Date

Notes

TM-180

Z-180

J-82

827

Keno AFS, OR

FPS-20A; FPS-67; FPS-6A; FPS-6A/-90

FPS-67B; FPS-6A; FPS-90. (FPS-67B only for JSS)

1959

BUIC-III. 827th Air Defense Group inactivated 30 Sept 1979. FAA joint-use site now, called ''Klamath Falls'' (data-tie only); FPS-90 sent to Salem, OR, JSS site (Z-345).

TM-180A

Z-180A

Yreka, CA

FPS-18

Sep-59

Dec-60

Gap-Filler Annex. Building is still extant. Located atop Gunsight Peak.

TM-180B

La Pine, OR

Gap-Filler Annex. Located atop Paulina Peak. Reportedly, the radar tower blew down during winter of 1958 - 1959, and was never rebuilt. The building was reportedly removed in 1987.

History of Keno AFS, OR

In 1959 the 827th AC&W Squadron began operating an AN/FPS-20A search radar and a pair of AN/FPS-6A height-finder radars. In June 1960 Keno joined the SAGE system. In 1960 Keno also was performing air-traffic-control duties for the FAA. In 1961 the search radar was upgraded and redesignated as an AN/FPS-67. In 1963 an AN/FPS-90 replaced one of the AN/FPS-6 height-finder radars, and the search radar was further upgraded to the AN/FPS-67B version. In 1979 the site came under TAC jurisdiction. In this time frame, the AN/FPS-90 was removed and sent to the new JSS site at Salem (Laurel Mtn./Dallas), OR. The remaining height-finder radar, now an AN/FPS-116, was retired circa 1988.

References: "Searching the Skies"; misc. ADCOM documents; eyewitness accounts.
