| Perm ID | Sage ID | JSS ID | Unit | Location | Early Equip. |
Final Equip. |
Oper. Date |
Inact. Date |
Notes |
|---|---|---|---|---|---|---|---|---|---|
| SM-163 | Z-163 | 865 | Las Vegas AFS, NV | FPS-3/-20A; MPS-14; FPS-27; FPS-26A | FPS-27; FPS-26A | 1956 | 31-Dec-69 | Family housing was at Nellis AFB. FAA site now known as Angel Peak, NV; FAA uses an AN/FPS-20A search radar. | |
| SM-163A | Z-163A | Boulder City, NV | FPS-18 | Oct-59 | Dec-60 | Gap-Filler Annex. Location was verified by Boulder City historian. | |||
| SM-163B | Z-163B | Lathrop Wells, NV | FPS-18 | Aug-59 | Dec-60 | Gap-Filler Annex. Shows on 1958 SAGE map as site P-59C; however, 1961 and 1962 SAGE maps show Joshua Tree as site P-59C. | |||
| SM-163C | Halloran Springs, CA ** | ** Gap-Filler Annex. In original ADC plans, but never was built | |||||||
| SM-163D | Wildrose Station, CA ** | ** Gap-Filler Annex. In original ADC plans, but never was built. |
Current Use: Still active. This now-FAA long-range radar site is now data-tied into the Joint Surveillance System (post 9/11). Lower camp is Spring Mtn. Youth Camp.
NOTICE:Some photos and documents may be marked with varying degrees of classification, up to SECRET. Data so marked is the way it was delivered from official USAF sources, and have been completely declassified. To the best of our knowledge, no currently classified data is stored on this site.The following site information is available: |
    |
