Information for Lewistown AFS, MT

Latitude: 47-13-03 N, Longitude: 109-13-19 W

Perm ID	Sage ID	JSS ID	Unit	Location	Early Equip.	Final Equip.	Oper. Date	Inact. Date	Notes
TM-178	Z-178		694	Lewistown AFS, MT	FPS-3A; FPS-6A; FPS-90	FPS-66A; FPS-6A	1960	30-Jun-71	Ops area / radar towers located north of Maiden on Judith Peak, ~ 24 road miles northeast of Lewistown. All Air Force buildings now removed; Judith Peak now a comm site. Cantonment/housing areas located down below, ~ 2 miles west of Maiden. Plans for an AN/FPS-24 or -35 FD search radar were cancelled.
TM-178A				Dodson, MT **	(FPS-18 planned)				Gap-Filler Annex. ** Planned but not built.

Perm ID

Sage ID

JSS ID

Unit

Location

Early
Equip.

Final
Equip.

Oper.
Date

Inact.
Date

Notes

TM-178

Z-178

694

Lewistown AFS, MT

FPS-3A; FPS-6A; FPS-90

FPS-66A; FPS-6A

1960

30-Jun-71

Ops area / radar towers located north of Maiden on Judith Peak, ~ 24 road miles northeast of Lewistown. All Air Force buildings now removed; Judith Peak now a comm site. Cantonment/housing areas located down below, ~ 2 miles west of Maiden. Plans for an AN/FPS-24 or -35 FD search radar were cancelled.

TM-178A

Dodson, MT **

(FPS-18 planned)

Gap-Filler Annex. ** Planned but not built.

History of Lewistown AFS, MT

The 694th AC&W Squadron began manual radar operations in Feb 1960 with AN/FPS-3A and AN/FPS-6 radars. A AN/FPS-90 height-finder radar was added a year later. Also, in March 1961 Lewistown began feeding the SAGE system. An AN/FPS-24 or -35 FD search radar was planned, but was subsequently cancelled. The AN/FPS-3A was removed in 1963, replaced by an AN/FPS-66 search set. This radar was upgraded to an AN/FPS-66A in 1966. The AN/FPS-90 was removed from service in 1968. The Air Force deactivated the 694th Radar Squadron (SAGE) on 30 June 1971.

References: "Searching the Skies"; misc. ADCOM documents; eyewitness accounts.
