Information for Lockport AFS, NY

Latitude: 43-08-25 N, Longitude: 078-50-05 W

Call Sign(s): Migrate

Perm ID	Sage ID	Unit	Location	Early Equip.	Final Equip.	Oper. Date	Inact. Date	Notes
P-21	Z-21	763	Lockport AFS, NY	CPS-6B (2); FPS-7; FPS-6, -6A (3) [2 for Army]; FPS-26	FPS-7 (FPS-107); FPS-26	1951	01-Apr-79	AN/FPS-7 later became AN/FPS-107. USAF site shared with Army for Nike Missile air-defense system (NF-17DC). GATR had been retained as JSS radio site, # G-56 (Sanborn - Lockport); however, is now closed.
CG24 / P-21E	Z-21E		Stoney Creek, ON, CN					** Gap-Filler Annex, planned but not completed. Appears to have been partially constructed.
P-21A	Z-21A		Brockport, NY	FPS-14		Aug-57	Jun-68	Gap-Filler Annex. Located at the far east side of the Lake View Cemetery just south of Brockport. Building is still extant.
P-21B	Z-21B		Charlotte Center, NY	FPS-14		Aug-57	Jun-68	Gap-Filler Annex. Both building and radar tower are still extant.

Perm ID

Sage ID

JSS ID

Unit

Location

Early
Equip.

Final
Equip.

Oper.
Date

Inact.
Date

Notes

P-21

Z-21

763

Lockport AFS, NY

CPS-6B (2); FPS-7; FPS-6, -6A (3) [2 for Army]; FPS-26

FPS-7 (FPS-107); FPS-26

1951

01-Apr-79

AN/FPS-7 later became AN/FPS-107. USAF site shared with Army for Nike Missile air-defense system (NF-17DC). GATR had been retained as JSS radio site, # G-56 (Sanborn - Lockport); however, is now closed.

CG24 / P-21E

Z-21E

Stoney Creek, ON, CN

** Gap-Filler Annex, planned but not completed. Appears to have been partially constructed.

P-21A

Z-21A

Brockport, NY

FPS-14

Aug-57

Jun-68

Gap-Filler Annex. Located at the far east side of the Lake View Cemetery just south of Brockport. Building is still extant.

P-21B

Z-21B

Charlotte Center, NY

FPS-14

Aug-57

Jun-68

Gap-Filler Annex. Both building and radar tower are still extant.

History of Lockport AFS, NY

The 763rd AC&W Squadron began operating a pair of AN/CPS-6B?s from this site in September 1951, taking over for the Lashup radar at Fort Niagara (L-19). These radars were phased out at the end of the decade. Meanwhile SAGE operations began at this site in December 1958. This site started operating an AN/FPS-7 radar in 1960. Height-finding chores were handled at that time by a pair of AN/FPS-6s. An Army Missile Master blockhouse was installed at Lockport AFS around this time to control the Nike missile batteries in the Buffalo - Niagara Falls Defense Area. During 1962 an AN/FPS-26 replaced one of these height-finder radars. [The Army also operated two FPS-6A height-finder radars in this time frame.] The other AN/FPS-6 was retired in 1968. The AN/FPS-7 was subsequently modified to an AN/FPS-107. The 763rd Radar Squadron (SAGE) was deactivated 1 April 1979. The GATR site had been retained as JSS radio site # G-56 (Sanborn - Lockport), but is now closed.

References: "Searching the Skies"; misc. ADCOM documents; eyewitness accounts.
