Information for Texarkana AFS, AR

Latitude: 33-27-20 N, Longitude: 093-59-53 W

Call Sign(s): Burly Boy,Jersey, Linden

Perm ID Sage ID JSS ID Unit Location Early
Equip.		 Final
Equip.		 Oper.
Date		 Inact.
Date		 Notes
M-91 Z-91   703 Texarkana AFS, AR FPS-3, FPS-20; MPS-14 FPS-91A; MPS-14 1955 08 Sep 1968 Plans for an AN/FPS-24 or -35 FD search radar were cancelled. Was an FAA site after USAF deactivation. However, this radar site is closed altogether now.
M-125B / M-91B       Heflin, LA **         ** Gap-Filler Annex. In original ADC plans, but never was built.
M-91A       Daingerfield, TX **         ** Gap-Filler Annex. In original ADC plans, but never was built.
M-91C       Tinsman, AR **         ** Gap-Filler Annex. In original ADC plans, but never was built.

Current Use: The former Texarkana AFS is inactive. A new 'Texarkana' FAA long-range radar facility (using an FPS-67 search radar) is located about 8 miles southeast of Texarkana, at 33-21-35N & 093-55-22W.

NOTICE:
Some photos and documents may be marked with varying degrees of classification, up to SECRET. Data so marked is the way it was delivered from official USAF sources, and have been completely declassified. To the best of our knowledge, no currently classified data is stored on this site.
The following site information is available:
